JR-3A WEDM Concentrated Ointment Gel for Wire Cutting Machine

JR-3A WEDM Concentrated Ointment

JR-3A WEDM concentrated ointment gel or JR-3A EDM gel has high concentration, environmental friendly character, fast processing speed, good finish and good chip removal, suitable for processing large thickness workpieces.

Product Specification

• Concentration Solution：Put the ointment into running water with a ratio 1:40-50 (ointment:water) and stir until mix the ointment into water thoroughly.
• Ingredients: Green product for the environment
• Using range: Specialized for all types of Wire-cutting Electric Discharge Machine ( WEDM—HS ). It can be also used as cooling liquid for grinder, lathe, miller and other kinds of black metal's machining processes.
• Features: The product is based on WEDM solid soap. It inherits the advantage of solid soap like high oil:water ratio, convenient shipping, and dissolves as quickly as oil.

  1. Uniform and white finish surface almost without stripe.

  2. Improve machining efficiency 30% more and surface finish degree one grade more.

  3. Improve machining process indexes especially when cutting workpiece thicker than 300mm.

  4. Workpiece is easy to take off and clean.

Specially suitable for multiple-cut of WEDM-HS.

• Expire Date：12 months
• Package： 2KG Special Plastic Bottle. 18KG / BOX, (2*9 bottles)
• Attention：Please do not mix other emulsified oil into the tank, otherwise, will decrease the performance .
